ARM Leaf Loader

Request Info Schedule Demo

A line of convertible (right or left pick-up) trailer-mounted, power-driven, vacuum leaf-loading machines. This tedious task just became a lot easier to overcome with this machine. It mulches the leaves and deposits them in the bed (hopper) of a tow vehicle.

Take advantage of the PA Act 101, Section 902 Grant. 902 Recycling Grant - Eligible Equipment Receives 90% Reimbursement
AVAILABLE IN PENNSYLVANIA. APPLY BY MAY 10TH.
We'll help you apply! (See Details)

FEATURES & HIGHLIGHTS

FOCUSED ON WHAT MATTERS

Model Trailer-Mounted Vacuum Leaf Loader is designed for one-person operation and capable of picking up leaves from curb sides, median strips, ditches, open spillways, and other areas. Further, the machine mulches the leaves and deposits them in the bed (hopper) of a tow vehicle.

SPECIFICATIONS

ARM LEAF LOADER AT A GLANCE

  • Manufacturer:

  • Class:

    ,

  • Power Source:

  • Blower Performance:

    16,600 CFM, 24,200 CFM

  • Pipe Diameter:

    16″

  • Country of Origin:

  • Build:

    Trailer-Mounted

    • *Exact specs may change without notice, or vary based on optional add-ons and features.

    ARM LEAF LOADER BENEFITS

    TO MAKE YOUR LIFE EASIER

  • Low cost leaf removal with right or left hand pickup.
  • Forward or rear intake design.
  • 16″ diameter hose heavy or light duty.
  • Direct drive Power Take-Off with over-center clutch protects engine from shock loads.
  • Low tip-to-housing clearance on suction fan creates hurricane-forced air flow.
  • 25″ and 30″ steel fan with six abrasion-resistant blades is statically and dynamically balanced.
  • 74 HP diesel engine collects debris at 2500 RPM.
  • 16,600 and 24,200 CFM available for highly efficient air and litter movement.

    • DOCUMENTS

    FOR THE ARM LEAF LOADER



    Additional information

    Manufacturer

    Class

    ,

    Power Source

    Blower Performance

    16,600 CFM, 24,200 CFM
    Pipe Diameter

    16″
    Country of Origin

    Build

    Trailer-Mounted
    Title Type Size
    ARM Trailer-Mounted Leaf Collectors Brochure application/pdf 4 MB
    ARM Model 2000 Leaf-Loader Specs application/pdf 699 KB
    ARM Model 1500 Leaf-Loader Specs application/pdf 758 KB
